Z-3100 is the upgraded version of ZEBEX middle-range handheld CCD scanner with faster scan rate, longer scanning depth and better decoding ability.
At a superior rate of 330 scans per second, ZEBEX proprietary Ultrascan hardware decoding technology empowers Z-3100 to decode the majority of 1D barcodes as well as GS1 DataBar.
It has working range up to 300 mm and is able to decode a barcode wider than 102 mm.
? Proprietary Ultrascan decoding technology
? Streamline design and Large trigger for effortless operation
? 32-bit micro processor unit
? Analog image capture technology
? Support presentation scan mode
? 0 ? 100,000 Lux light immunity
? Captures barcodes on mobile phone, tablet, or computer screens
Specifications
OPERATIONAL
Light Source: 617 nm visible LED
Optical System: Linear CCD array
Microprocessor: 32-bit
Depth of Field:
4 mil: 0 ? 60 mm
5 mil: 0 ? 100 mm
7.5 mil: 0 ? 180 mm
10 mil: 0 ? 220 mm
13 mil: 0 ? 285 mm
20 mil: 0 ? 350 mm
Note: DOF may vary depending on environment condition and barcode quality.
5 mil: 0 ? 100 mm
7.5 mil: 0 ? 180 mm
10 mil: 0 ? 220 mm
13 mil: 0 ? 285 mm
20 mil: 0 ? 350 mm
Note: DOF may vary depending on environment condition and barcode quality.
Scan Angle: 42?
Scan Rate: 330 scans per second
Print Contrast: 30% @ UPC/EAN 100%
Indicator: Blue LED
Programmable Operation: Programmable tone & beep time
System Interface: Keyboard, RS-232, HID USB, USB Virtual COM, wand, OPOS, JPOS
PHYSICAL CHARACTERISTICS
Dimensions H x W x L: 152.3 ? 64.4 ? 104.9 mm (device only)
Weight (g): 84 g (device only)
Cable: Standard 2M straight
POWER
Input Voltage: 5 VDC ?10%
Operating Current: 100 mA @ 5V ( Typical )
ENVIRONMENT & SAFETY
Operating Temperature: 0 ?C to 50 ?C
Storage Temperature: -20?C to 60?C
Humidity: 5 to 95%, non-condensing
Light Level: Max. 100,000 Lux (fluorescence)
Drop Durability: Designed to withstand 1.5M drops
